Zoom Stereo Microscope GHEXA-23.0203-T
| Parameter | Value |
|---|---|
| Product Name | Trinocular Zoom Stereo Microscope (0.7–6.3×, 1:9) |
| Model | GHEXA-23.0203-T |
| Head | Trinocular, 45° inclined, 360° rotatable, interpupillary distance 54–75 mm, light split 100:0 / 20:80 |
| Eyepieces | Wide Field WF10×/22 mm (high eyepoint, pair, diopter adjustable) |
| Zoom Magnification | 0.7–6.3× continuous zoom (zoom ratio 1:9) |
| Total Magnification | 7×–63× (standard with WF10× eyepieces) |
| Working Distance | 110 mm (standard configuration) |
| Objective Lens | Built-in zoom optics, parfocal throughout zoom range |
| Stand | Track stand with coarse focusing knob, tension adjustable |
| Stage | Large base plate 310×280 mm with black/white reversible stage plate and stage clips |
| Illumination | Reflected: 3W LED (top, adjustable intensity) + Transmitted: 3W LED (bottom, adjustable intensity) |
| Focusing | Rack & pinion coarse focus, travel range ~50 mm, tension adjustable |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | 1 pc per carton, dimensions 59×43×42 cm, gross/net weight 9/7 kg |
Payment. Payment upon receipt of goods, Payment by card in the department, Google Pay, Online card, -5% discount in case of payment
Warranty. The Consumer Protection Act does not provide for the return of this product of proper quality.
Description
GHEXA-23.0203-T
GHEXA-23.0203-T is a high-performance trinocular zoom stereo microscope with a continuous 0.7–6.3× zoom range (1:9 ratio) and 110 mm long working distance, delivering sharp, erect, three-dimensional images with excellent depth of field. Equipped with wide-field WF10×/22 mm eyepieces, a robust track stand, large 310×280 mm base stage, and dual 3W LED illumination (reflected + transmitted), this model offers versatile, ergonomic observation for inspection, assembly, quality control, and educational use in electronics, precision manufacturing, materials science, biology sample preparation, gemology, and university teaching laboratories.
Specifications
| Parameter | Value |
|---|---|
| Product Name | Trinocular Zoom Stereo Microscope (0.7–6.3×, 1:9) |
| Model | GHEXA-23.0203-T |
| Head | Trinocular, 45° inclined, 360° rotatable, interpupillary distance 54–75 mm, light split 100:0 / 20:80 |
| Eyepieces | Wide Field WF10×/22 mm (high eyepoint, pair, diopter adjustable) |
| Zoom Magnification | 0.7–6.3× continuous zoom (zoom ratio 1:9) |
| Total Magnification | 7×–63× (standard with WF10× eyepieces) |
| Working Distance | 110 mm (standard configuration) |
| Objective Lens | Built-in zoom optics, parfocal throughout zoom range |
| Stand | Track stand with coarse focusing knob, tension adjustable |
| Stage | Large base plate 310×280 mm with black/white reversible stage plate and stage clips |
| Illumination | Reflected: 3W LED (top, adjustable intensity) + Transmitted: 3W LED (bottom, adjustable intensity) |
| Focusing | Rack & pinion coarse focus, travel range ~50 mm, tension adjustable |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | 1 pc per carton, dimensions 59×43×42 cm, gross/net weight 9/7 kg |
Key Applications & Uses
- Electronics & PCB inspection — Detailed examination of solder joints, component placement, surface defects, and microcircuits at low to medium magnification.
- Precision assembly & rework — Assembly of small mechanical parts, jewelry, watch components, miniature devices, and medical instruments with comfortable 110 mm working distance.
- Materials science & failure analysis — Surface topography observation of metals, polymers, composites, fractures, coatings, and welds in industrial QA/QC labs.
- Biological sample preparation & dissection — Stereo viewing of plant/animal tissues, insects, seeds, fossils, and specimens during preparation for higher-magnification microscopy.
- Gemology, mineralogy & forensics — Grading gemstones, identifying inclusions, examining mineral crystals, tool marks, fibers, and trace evidence.
- Educational & training use — University practicals in biology, geology, engineering, and microscopy courses; trinocular port enables camera attachment for live demonstration or recording.
Why Choose from G-Hexa?
- Wide 1:9 zoom ratio — Smooth, continuous 0.7–6.3× magnification range provides seamless transition from overview (7×) to detailed inspection (63×) without changing objectives.
- Generous 110 mm working distance — Ample space for manipulating tools, probes, or samples under the lens — essential for assembly, dissection, and soldering tasks.
- Dual high-intensity 3W LED illumination — Independent reflected and transmitted LEDs deliver bright, cool, long-life lighting (50,000+ hours) with adjustable intensity for optimal contrast on opaque or translucent specimens.
- Large, stable platform — 310×280 mm base stage offers plenty of room for large samples, petri dishes, circuit boards, or multi-specimen observation.
- Trinocular digital-ready design — Dedicated phototube allows easy connection of cameras for documentation, teaching projections, or image analysis software integration.
- G-Hexa reliability & value — Precision-engineered optics at competitive pricing, backed by expert support, 1-year warranty, fast delivery from Pune stock, and accessories (auxiliary objectives, ring lights, stands) available for customization.
Frequently Asked Questions (FAQs)
Q: What is the magnification range of GHEXA-23.0203-T? A: The zoom body provides 0.7–6.3× magnification; with standard WF10×/22 mm eyepieces, total magnification ranges from 7× to 63×. Optional 15× or 20× eyepieces can extend this further.
Q: Can I attach a digital camera or microscope camera? A: Yes — the trinocular head includes a dedicated phototube (typically C-mount compatible with adapter) for connecting USB, HDMI, or Wi-Fi cameras for live viewing, capture, and measurement.
Q: Is the illumination adjustable for different sample types? A: Both reflected (top) and transmitted (bottom) 3W LEDs have independent intensity controls, allowing you to optimize contrast for reflective surfaces, transparent samples, or mixed lighting needs.
Q: What is the advantage of the 110 mm working distance? A: The long 110 mm WD provides ample clearance for tools, hands, or larger samples, making it ideal for manipulation, soldering, dissection, or observing bulky objects without obstruction.
Q: Is this microscope suitable for educational use? A: Absolutely — its ergonomic design, wide field of view, stable track stand, and trinocular camera port make it excellent for university teaching labs, student practicals, and group demonstrations.
Q: Can I increase magnification beyond 63×? A: Yes — add auxiliary objective lenses (e.g., 0.5× or 2×) or higher-magnification eyepieces (15×/16 mm or 20×) from G-Hexa to extend the range while maintaining working distance compatibility.
