Multi-Viewing Microscope GHEXA-17.0940
| Parameter | Value |
|---|---|
| Product Name | Multi-Viewing (10-Head) Microscope System |
| Model | GHEXA-17.0940 |
| Viewing Heads | 1 × Trinocular head (30° inclined, 360° rotatable) + 9 × Binocular heads (30° inclined, 360° rotatable), synchronized focusing & identical image sharing |
| Eyepieces | Plan WF10×/22 mm (high eyepoint, wide field, diopter adjustable), 1 pair per head (total 20 eyepieces) |
| Nosepiece | Quintuple (5-position), reversed ball-bearing |
| Objectives | Infinity-corrected Plan Achromatic: 4×, 10×, 20×, 40× (spring), 100× (spring, oil immersion) |
| Stage | Double-layer mechanical stage 175×145 mm, right-hand low-position coaxial X/Y controls, moving range 76×52 mm (approx.), spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing for main unit, synchronized fine focus on all secondary heads, tension adjustable, upper limit stop |
| Condenser | Swing-out Abbe condenser N.A. 0.9/0.13 (dry), with iris diaphragm and filter holder |
| Illumination | 10W high-brightness LED (Koehler illumination), adjustable intensity, long life (>50,000 hours) |
| Multi-Head Connectivity | Optical bridge system with pointer (LED arrow) for instructor guidance |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | 1 complete system per carton, dimensions 43.9×41.6×55 cm, gross/net weight 15.5/11 kg |
Payment. Payment upon receipt of goods, Payment by card in the department, Google Pay, Online card, -5% discount in case of payment
Warranty. The Consumer Protection Act does not provide for the return of this product of proper quality.
Description
GHEXA-17.0940
GHEXA-17.0940 is a professional multi-viewing (multi-head) teaching and demonstration microscope system designed for simultaneous observation by up to 10 users (1 trinocular head + 9 binocular heads). Featuring high-eyepoint Plan WF10×/22 mm eyepieces, a quintuple reversed nosepiece, infinity-corrected plan achromatic objectives (4×, 10×, 20×, 40×, 100× oil), a large 175×145 mm double-layer mechanical stage, powerful 10W LED illumination with adjustable intensity, and a swing-out Abbe condenser, this model ensures identical, high-contrast, sharp images for all viewers — making it the ideal choice for interactive teaching in universities, medical colleges, training centers, pathology labs, and group demonstrations in research or industrial settings.
Specifications
| Parameter | Value |
|---|---|
| Product Name | Multi-Viewing (10-Head) Microscope System |
| Model | GHEXA-17.0940 |
| Viewing Heads | 1 × Trinocular head (30° inclined, 360° rotatable) + 9 × Binocular heads (30° inclined, 360° rotatable), synchronized focusing & identical image sharing |
| Eyepieces | Plan WF10×/22 mm (high eyepoint, wide field, diopter adjustable), 1 pair per head (total 20 eyepieces) |
| Nosepiece | Quintuple (5-position), reversed ball-bearing |
| Objectives | Infinity-corrected Plan Achromatic: 4×, 10×, 20×, 40× (spring), 100× (spring, oil immersion) |
| Stage | Double-layer mechanical stage 175×145 mm, right-hand low-position coaxial X/Y controls, moving range 76×52 mm (approx.), spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing for main unit, synchronized fine focus on all secondary heads, tension adjustable, upper limit stop |
| Condenser | Swing-out Abbe condenser N.A. 0.9/0.13 (dry), with iris diaphragm and filter holder |
| Illumination | 10W high-brightness LED (Koehler illumination), adjustable intensity, long life (>50,000 hours) |
| Multi-Head Connectivity | Optical bridge system with pointer (LED arrow) for instructor guidance |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | 1 complete system per carton, dimensions 43.9×41.6×55 cm, gross/net weight 15.5/11 kg |
Key Applications & Uses
- Interactive classroom teaching in universities, medical colleges, and biology/microbiology departments — allows 1 instructor (trinocular head) + 9 students to view the same specimen simultaneously with identical orientation and focus.
- Group training & practical demonstrations in pathology, histology, parasitology, hematology, and cytology labs — ideal for side-by-side discussion of blood smears, tissue sections, parasite morphology, and stained preparations.
- Instructor-guided sessions — Built-in LED pointer enables the teacher to highlight specific features on the shared image for real-time explanation and student engagement.
- Professional training workshops — Used in pharma, biotech, and industrial QA/QC training programs for standardized observation of microbiological cultures, material samples, and quality control specimens.
- Digital integration — Trinocular head supports camera attachment for live projection to large screens, recording, or remote viewing during lectures and seminars.
- Collaborative research reviews — Enables multiple researchers or pathologists to examine and discuss the same slide without changing positions or losing context.
Why Choose from G-Hexa?
- True 10-user simultaneous viewing — 1 trinocular + 9 binocular heads with perfect optical synchronization ensure every viewer sees the exact same high-resolution, correctly oriented image — no rotation or parallax issues.
- Wide-field, high-eyepoint optics — Plan WF10×/22 mm eyepieces provide a spacious 22 mm field of view and comfortable viewing even for eyeglass wearers during long practical sessions.
- Superior infinity plan objectives — Flat-field, high-contrast images from 40× to 1000× (oil) with excellent color fidelity, ideal for detailed cellular, tissue, and microbial observation.
- Powerful & efficient 10W LED — Bright, cool, uniform Koehler illumination with long bulb life and low heat output — protects specimens and reduces energy costs in multi-hour teaching labs.
- User-friendly & durable design — Rackless-style stage movement, swing-out condenser for quick objective access, coaxial controls, and robust optical bridge system built for heavy daily use in educational environments.
- G-Hexa educational excellence — Competitive pricing for a full 10-head system, backed by expert installation support, 1–2 year warranty, fast delivery from Pune stock, and dedicated assistance for lab setup and training.
Frequently Asked Questions (FAQs)
Q: How many people can observe simultaneously with GHEXA-17.0940? A: Up to 10 users — 1 instructor via the trinocular head and 9 students via the binocular heads — all viewing the identical, synchronized image.
Q: Does the instructor have a pointer to guide students? A: Yes — the system includes a built-in LED arrow pointer controlled from the trinocular head, allowing the instructor to highlight specific areas of the specimen for clear explanation.
Q: Can a digital camera be attached for projection or recording? A: Yes — the trinocular head features a dedicated phototube (C-mount compatible with adapter) for attaching microscope cameras, enabling live display on monitors, projectors, or recording for lectures.
Q: What is the maximum magnification? A: With the standard WF10×/22 mm eyepieces and 100× oil objective, the system achieves 1000× total magnification, suitable for observing fine cellular details, bacteria, and blood elements.
Q: Is the stage large enough for standard slides and other specimens? A: The 175×145 mm double-layer mechanical stage easily accommodates standard 25×75 mm or 26×76 mm slides, with smooth coaxial controls and sufficient travel range for scanning large areas.
Q: Is this microscope suitable only for teaching, or can it be used in diagnostic labs? A: While optimized for multi-user teaching and training, its high-quality infinity plan optics, bright LED illumination, and trinocular camera port make it excellent for group consultations and multi-observer diagnostic reviews in pathology and clinical labs. For single-head routine diagnostics, consider our standard clinical series.
