Multi View Microscope GHEXA-17.0950-5
| Parameter | Value |
|---|---|
| Product Name | 5-Head Multi-Viewing Microscope System |
| Model | GHEXA-17.0950-5 |
| Viewing Heads | 1 × Trinocular head (30° inclined, 360° rotatable) + 4 × Binocular heads (30° inclined, 360° rotatable), optical bridge system with synchronized image sharing |
| Eyepieces | Plan PL10×/22 mm (high eyepoint, wide field, diopter adjustable), 1 pair per head (total 10 eyepieces) |
| Nosepiece | Sextuple (6-position) brightfield with slots for DIC prism and polarizing kit |
| Objectives | Infinity-corrected Plan Achromatic: 4×, 10×, 20×, 40× (spring), 100× (spring, oil immersion) |
| Stage | Double-layer mechanical stage 187×166 mm, right-hand low-position coaxial X/Y controls, moving range 80×55 mm, spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing on main unit, synchronized fine focus on all secondary heads, tension adjustable, upper limit stop |
| Condenser | Swing-out Abbe condenser N.A. 0.9/0.13 (dry), with iris diaphragm and filter holder |
| Illumination | High-brightness LED (Koehler illumination), adjustable intensity, long life (>50,000 hours) |
| Multi-Head Features | Built-in LED pointer (arrow) for instructor guidance, uniform image orientation across all heads |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | Secure multi-crate shipment (weight & dimensions vary by configuration), contact G-Hexa for exact logistics |
Payment. Payment upon receipt of goods, Payment by card in the department, Google Pay, Online card, -5% discount in case of payment
Warranty. The Consumer Protection Act does not provide for the return of this product of proper quality.
Description
GHEXA-17.0950-5
GHEXA-17.0950-5 is a professional 5-head multi-viewing microscope system engineered for collaborative teaching, training, and group consultations in advanced laboratory environments. This configuration features 1 trinocular head + 4 binocular heads for simultaneous viewing by up to 5 users with perfectly synchronized, identical images. It incorporates wide-field PL10×/22 mm eyepieces, a sextuple brightfield nosepiece with dedicated slots for DIC and polarizing (PL) upgrades, infinity-corrected plan achromatic objectives (4×, 10×, 20×, 40×, 100× oil), an extra-large 187×166 mm double-layer mechanical stage with 80×55 mm travel, swing-out condenser, and powerful LED illumination — delivering high-resolution, flat-field performance ideal for interactive pathology reviews, medical education, microbiology training, and multi-observer research discussions.
Specifications
| Parameter | Value |
|---|---|
| Product Name | 5-Head Multi-Viewing Microscope System |
| Model | GHEXA-17.0950-5 |
| Viewing Heads | 1 × Trinocular head (30° inclined, 360° rotatable) + 4 × Binocular heads (30° inclined, 360° rotatable), optical bridge system with synchronized image sharing |
| Eyepieces | Plan PL10×/22 mm (high eyepoint, wide field, diopter adjustable), 1 pair per head (total 10 eyepieces) |
| Nosepiece | Sextuple (6-position) brightfield with slots for DIC prism and polarizing kit |
| Objectives | Infinity-corrected Plan Achromatic: 4×, 10×, 20×, 40× (spring), 100× (spring, oil immersion) |
| Stage | Double-layer mechanical stage 187×166 mm, right-hand low-position coaxial X/Y controls, moving range 80×55 mm, spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing on main unit, synchronized fine focus on all secondary heads, tension adjustable, upper limit stop |
| Condenser | Swing-out Abbe condenser N.A. 0.9/0.13 (dry), with iris diaphragm and filter holder |
| Illumination | High-brightness LED (Koehler illumination), adjustable intensity, long life (>50,000 hours) |
| Multi-Head Features | Built-in LED pointer (arrow) for instructor guidance, uniform image orientation across all heads |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Packaging | Secure multi-crate shipment (weight & dimensions vary by configuration), contact G-Hexa for exact logistics |
Key Applications & Uses
- Medical & pathology teaching in medical colleges, universities, and hospitals — allows 1 instructor (trinocular head) + 4 students/residents to simultaneously observe and discuss histopathology slides, cytology smears, blood films, and tissue sections.
- Group diagnostic consultations — Enables pathologists, microbiologists, or hematologists to review the same slide together for consensus on difficult cases, tumor grading, infectious agents, or abnormal cells.
- Advanced training workshops — Ideal for pharma, biotech, and clinical laboratory staff training in microscopy techniques, parasite identification, Gram staining, acid-fast bacilli detection, and quality control procedures.
- Research group reviews — Facilitates collaborative examination of cell cultures, immunofluorescence preparations, material microstructures, or failure analysis samples in multi-user settings.
- Instructor-led demonstrations — LED pointer from the trinocular head highlights key features in real time, enhancing explanation of cellular morphology, staining patterns, or diagnostic criteria.
- Digital integration — Trinocular port supports camera attachment for live projection to monitors, recording sessions, or remote sharing during teaching or telepathology consultations.
Why Choose from G-Hexa?
- True synchronized multi-user viewing — All 5 heads display the identical, correctly oriented, high-resolution image with no rotation or delay — critical for accurate group interpretation and teaching.
- Upgrade-ready sextuple nosepiece — Built-in slots for DIC and polarizing accessories allow future expansion to differential interference contrast or polarized light microscopy without replacing the system.
- Extra-large stage & precise movement — 187×166 mm stage with 80×55 mm travel accommodates large slides, multi-well plates, or extended scanning — perfect for detailed slide reviews and teaching demonstrations.
- Wide-field, comfortable optics — PL10×/22 mm high-eyepoint eyepieces provide a spacious viewing field and reduced eye strain during prolonged group sessions.
- Professional-grade illumination & build — Bright, cool LED Koehler lighting, swing-out condenser for fast objective changes, and robust optical bridge system ensure reliability in high-usage educational and clinical environments.
- G-Hexa expertise & support — Tailored for Indian laboratories with competitive pricing, expert installation guidance, 1–2 year warranty, fast delivery from Pune stock, and dedicated after-sales service for multi-head systems.
Frequently Asked Questions (FAQs)
Q: How many users can observe at the same time with GHEXA-17.0950-5? A: Up to 5 users simultaneously — 1 via the trinocular head (ideal for the instructor) and 4 via binocular heads — all seeing the exact same synchronized image.
Q: Does the system include a pointer for teaching? A: Yes — an integrated LED arrow pointer, controlled from the trinocular head, allows the instructor to highlight specific areas of the specimen for clear, real-time guidance.
Q: Can I attach a camera for projection or recording? A: Yes — the trinocular head includes a dedicated phototube (C-mount compatible with adapter) for connecting digital cameras, enabling live display on screens, projectors, or image capture for documentation.
Q: What is the maximum magnification? A: With PL10×/22 mm eyepieces and the 100× oil objective, the system achieves 1000× total magnification, suitable for detailed cellular, bacterial, and histological observation.
Q: Is the microscope suitable for DIC or polarizing observation? A: The sextuple nosepiece has built-in slots for DIC prisms and polarizing components. These advanced contrast methods can be added as optional upgrades — contact G-Hexa for compatible kits and configuration.
Q: How durable is the multi-head system for daily lab use? A: Built with high-quality optics, robust mechanical bridge, and LED illumination designed for heavy educational/clinical workloads, it offers long-term reliability with minimal maintenance — backed by G-Hexa’s comprehensive warranty and support.
