Microscope GHEXA-11.5121-T
| Parameter | Value |
|---|---|
| Product Name | Trinocular Teaching Microscope Kit |
| Model | GHEXA-11.5121-T |
| Head | Trinocular, 360° rotatable, 45° inclined, interpupillary distance adjustable 54–75 mm, fixed 50/50 or 100/0 light split |
| Eyepieces | Wide Field WF10x (pair, standard) + WF16x (pair, included) |
| Nosepiece | Quadruple, reversed ball-bearing |
| Objectives | Achromatic 4x, 10x, 40x (spring), 100x (spring, oil immersion) |
| Stage | Double-layer mechanical stage 115×125 mm with coaxial X/Y controls and spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing knobs, coarse stroke ~22 mm, fine adjustment 0.002 mm/division, tension adjustable, safety upper stop |
| Condenser | Abbe N.A. 1.25 with iris diaphragm and filter holder |
| Illumination | Built-in LED with adjustable intensity (corded) |
| Camera Port | 0.3x C-Mount adapter (integrated for microscope cameras) |
| Included Accessories | 10 prepared glass slides (permanent mounts), student experiment kit (blank slides, cover slips, stains, tools, etc.), hand-carry case |
| Power Supply | 100–240V AC adapter included |
| Packaging | 1 pc per carton, dimensions 30×20×40 cm, gross/net weight 4.5/4 kg |
Payment. Payment upon receipt of goods, Payment by card in the department, Google Pay, Online card, -5% discount in case of payment
Warranty. The Consumer Protection Act does not provide for the return of this product of proper quality.
Description
GHEXA-11.5121-T
GHEXA-11.5121-T is a versatile trinocular teaching microscope kit designed for educational institutions, undergraduate labs, and introductory research training. It combines comfortable trinocular viewing, wide-field WF10x and WF16x eyepieces, a quadruple achromatic objective set (4x, 10x, 40x, 100x oil), large 115×125 mm mechanical stage with coaxial focusing, bright LED illumination, a 0.3x C-mount for digital camera integration, plus a complete educational package: 10 high-quality prepared slides, a full student experiment kit, protective hand-carry case, and secure carton packaging — delivering everything needed for hands-on microscopy, image capture, and classroom demonstrations.
Specifications
| Parameter | Value |
|---|---|
| Product Name | Trinocular Teaching Microscope Kit |
| Model | GHEXA-11.5121-T |
| Head | Trinocular, 360° rotatable, 45° inclined, interpupillary distance adjustable 54–75 mm, fixed 50/50 or 100/0 light split |
| Eyepieces | Wide Field WF10x (pair, standard) + WF16x (pair, included) |
| Nosepiece | Quadruple, reversed ball-bearing |
| Objectives | Achromatic 4x, 10x, 40x (spring), 100x (spring, oil immersion) |
| Stage | Double-layer mechanical stage 115×125 mm with coaxial X/Y controls and spring-loaded specimen holder |
| Focusing | Coaxial coarse & fine focusing knobs, coarse stroke ~22 mm, fine adjustment 0.002 mm/division, tension adjustable, safety upper stop |
| Condenser | Abbe N.A. 1.25 with iris diaphragm and filter holder |
| Illumination | Built-in LED with adjustable intensity (corded) |
| Camera Port | 0.3x C-Mount adapter (integrated for microscope cameras) |
| Included Accessories | 10 prepared glass slides (permanent mounts), student experiment kit (blank slides, cover slips, stains, tools, etc.), hand-carry case |
| Power Supply | 100–240V AC adapter included |
| Packaging | 1 pc per carton, dimensions 30×20×40 cm, gross/net weight 4.5/4 kg |
Key Applications & Uses
- Classroom and laboratory teaching in biology, microbiology, botany, zoology, and general science at high schools, colleges, and universities — perfect for binocular observation and simultaneous digital imaging.
- Student practicals on cell structure, mitosis, bacterial staining, plant/animal tissues, blood smears, protozoa, algae, and basic histological techniques.
- Direct digital documentation via the 0.3x C-mount — connect USB microscope cameras for live viewing, image capture, measurements, and student report generation.
- Instructor-guided sessions and group demonstrations — trinocular design allows one user to view through eyepieces while projecting the image to a screen or monitor for the class.
- Portable microscopy setups for science fairs, outreach programs, workshops, coaching centers, and small training labs requiring easy transport and quick setup.
Why Choose from G-Hexa?
- Trinocular flexibility for teaching & imaging — Dedicated C-mount port with 0.3x reduction lens enables seamless connection of digital cameras while maintaining comfortable eyepiece viewing — ideal for hybrid classroom environments.
- Extended magnification & dual eyepieces — WF10x and WF16x pairs provide 40×–1600× range, allowing detailed observation of microorganisms, cell organelles, and fine structures.
- Complete ready-to-teach kit — Includes 10 professional prepared slides, comprehensive experiment kit, and durable hand-carry case — saves setup time and cost for educators and lab managers.
- Modern, eye-friendly LED — Cool, adjustable LED illumination ensures long bulb life, no heat damage to specimens, and consistent brightness for prolonged practical sessions.
- Ergonomic student design — Coaxial controls, large mechanical stage, and adjustable interpupillary distance make operation intuitive and comfortable for learners of all levels.
- G-Hexa educational value — Affordable pricing, reliable 1-year warranty, fast delivery from Pune stock, and dedicated support — perfect for outfitting multiple classrooms or upgrading teaching facilities.
Frequently Asked Questions (FAQs)
Q: Can I capture images or videos with GHEXA-11.5121-T? A: Yes — the built-in 0.3x C-mount allows direct attachment of compatible microscope cameras (USB or HDMI) for live viewing, photography, and video recording on a computer or monitor.
Q: What is included in the student experiment kit? A: It typically contains blank slides, cover slips, basic biological stains (e.g., methylene blue, iodine), droppers, forceps, teasing needles, cotton swabs, and simple experiment guides for common practicals.
Q: Are the 10 prepared slides labeled and permanent? A: Yes — they are high-quality, stained, permanent microscope slides with clear labels, covering standard educational topics such as plant cells, animal tissues, blood, bacteria, and more.
Q: What is the maximum magnification? A: Using the WF16x eyepieces and 100x oil objective, the microscope reaches up to 1600× total magnification, suitable for observing fine cellular details and microorganisms.
Q: Is the LED illumination corded or rechargeable? A: The standard configuration uses a corded 100–240V AC adapter. Rechargeable battery options may be available — please contact G-Hexa to check for your specific needs.
Q: Is this model suitable only for teaching, or can it be used in small research labs? A: It is optimized for educational and introductory lab use. For advanced research applications requiring plan achromatic objectives, phase contrast, or higher-resolution imaging, consider our professional trinocular series available on ghexa.com.
